When the corresponding indicator icon (yellow) on the combination instrument panel is illuminated or when the remaining illumination of the instrument panel is less than or equal to 25%, the pure electric vehicle must be charged at this time. (Note: The charging temperature requires 0 ℃ -55 ℃, and the discharge temperature requires -20 ℃ -60 ℃)

　　The specific operation steps are as follows:

　　1. The vehicle should be parked indoors away from flammable and explosive materials, with the gear lever in "P" position, the handbrake applied, and the ignition switch turned to "OFF"

　　2. Check the coolant to confirm whether the level is normal. Check the socket of Charging station to ensure safety and reliability.

　　3. When charging, first plug in the power supply end of the "AC charging cable"; Afterwards, pull up the unlock switch on the left side of the driver's seat, open the charging port cover, and insert the "AC charging cable" on the vehicle end.

　　4. When the corresponding icon (red) on the combination instrument panel illuminates, it indicates that the charging link device has been connected normally. When the corresponding icon (yellow) on the combination instrument panel lights up, it indicates that the electric vehicle battery has started charging.

　　5. After the corresponding icon (yellow) of the combination instrument goes out, it indicates that the power battery has been fully charged. Please unplug the "AC charging line" from the vehicle end first, then unplug the "AC charging line" power supply section, close the charging port, and organize the AC charging line.

　　Relevant precautions:

　　1. In order to shorten the charging time, it is not recommended to use on-board electrical equipment during the vehicle charging process when the temperature empty box related functions of the automatic start in the vehicle are normal.

　　2. Charging at low temperatures and air conditioning heating the battery are normal.

　　3. If you encounter a malfunction during the charging process of an electric vehicle battery, please seek professional assistance and do not attempt repairs without authorization.
