Lithium manganese oxide battery parameters

　　Nominal voltage: 3.7v

　　Output voltage range: 2.5-4.2v nominal capacity: 7500mAh

　　Standard continuous discharge current: 0.2C

　　Maximum continuous discharge current: 1C

　　Working temperature: Charging: 0-45 ℃

　　Discharge: -20~60 ℃

　　Product size: MAX 19.2 * 56.5 * 69.5mm

　　Finished product internal resistance: ≤ 200m Ω

　　Lead model: National standard line UL3302/26 #, line length 50mm, white line 10K NTC

　　Protection board parameters: (Each parameter can be set according to the customer's product)

　　Overcharge protection voltage/4.28 ± 0.025V per string

　　Overdischarge protection voltage 2.4 ± 0.1V

　　Overcurrent value: 2-4A
